Louna™ Acoustical Ceiling - LC665

Louna Acoustic False Ceiling Tiles are designed with Mineral Wool with monolithic visual reducing installation time


Add to Bucket
Performance & Specifications Product Items Documents & Files Cad & Revit Installation
Features
  • Soft Fiber substrate with monolithic visual reducing installation time
  • Exceptional Sound Absorption with NRC values up to 1
  • High Light Reflectance (LR-0.88) reduces light fixtures & Energy use
  • Washable & Scrubbable finish
  • Impact & Scratch Resistant
  • Available in Plank Sizes compatible with Logix Integrated Ceiling System
  • Available in baffle sizes
Specifications
Physical Properties
  • Materials Classification: Type: XII, Form: 2, Pattern: G
  • Substrate and Surface Finish: Mineral Wool substrate finished with painted fiberglass scrim
  • Thickness: 15mm, 19mm, 25mm, 38mm
  • Size: 600 x 600mm, 610 x 610mm, 600 x 1200mm, 610 x 1220mm
  • Edge Detail Trim: Square, Reveal [SL, FL] Concealed [D-BESK, S-BESK]
  • Weight: 15mm [1.7 kg/m²], 19mm [2.1 kg/m²], 25mm [2.7 kg/m²], 38mm [4 kg/m²]
  • Noise Reduction Coefficient [NRC]: [0.85] [0.9] [0.95]
  • Ceiling Attenuation Class [CAC]: [24 dB] [28 dB] [30dB] [35 dB]
  • Mold Prevention Application as per ASTM D3273: Soft fiber substrate is inherently resistant to the growth of mold and mildew
  • Humidity Resistance: Maximum 99% RH / 40°C for ClimaPlus
  • Light Reflectance Coefficient [LR]: 0.88
  • Color: Standard White similar to RAL 9016. Other colors are available upon request
  • Surface Burning Characteristics as per ASTM E84: Class A, Flame Spread: 25, Smoke development: 50
  • Thermal Resistance: 15mm [0.44 m² °K/W], 19mm [0.6 m² °K/W - R 3.5], 25mm [0.74 m² °K/W - R 4.2], 38mm [1.12 m² °K/W- R 6.6]
  • Washability / Scrubbability as per ASTM D4828 & D2486: Exceeds 1000 Wash/Scrub cycles without surface break or the extent of abrasion upon request
  • Relevant LEED Credit: EA Credit 1 | MR Credit 4| MR Credit 5 | MR Credit 6 IEQ Credit 3 | IEQ Credit 3.2 | IEQ Credit 4.6 | IEQ Credit 8.1 | IEQ Credit 9
Applications
  • Lobbies
  • Waiting Areas
  • Restaurants
  • Receptions & Offices
  • Open-Plan areas
Catalogue

Item

Size

Color

Edges

CAC

NRC

LC665
600*600*15
White
SQ
24
0.85
Order Sample
LC665
600*600*15
Grey
SQ
24
0.85
Order Sample
LC665
600*600*15
Dark Grey
SQ
24
-
Order Sample
LC665
600*600*15
Yellow
SQ
24
-
Order Sample
LC665
600*600*15
Green
SQ
24
-
Order Sample
LC225
610*610*15
Green
SQ
24
0.85
Order Sample
LC669
600*600*19
Green
SQ
24
0.95
Order Sample
LC229
610*610*19
Green
SQ
24
0.95
Order Sample
LC629
600*1200*19
Green
SQ
24
0.95
Order Sample
LC249
610*1220*19
Green
SQ
24
0.95
Order Sample
LC6625
600*600*25
Green
SQ
28
0.95
Order Sample
LC2225
610*610*25
Green
SQ
28
0.95
Order Sample
LCR6225
600*1200*25
Green
SL
30
0.95
Order Sample
LCR2425
610*1220*25
Green
SL
30
0.95
Order Sample
LCR6625
600*600*25
Green
SL
30
0.95
Order Sample
LCR2225
610*610*25
Green
SL
30
0.95
Order Sample
LCRF6225
600*1200*25
Green
FL
30
0.95
Order Sample
LCRF2425
610*1220*25
Green
FL
30
0.95
Order Sample
LCRF6625
600*600*25
Green
FL
30
0.95
Order Sample
LCRF2225
610*610*25
Green
FL
30
0.95
Order Sample
LCRFDC669
600*600*19
Green
D-Besk
28
0.9
Order Sample
LCRFDC229
610*610*19
Green
D-Besk
28
0.9
Order Sample
LCRFDC6625
600*600*25
Green
D-Besk
30
0.95
Order Sample
LCRFDC2225
610*610*25
Green
D-Besk
30
0.95
Order Sample
LCRFDC6638
600*600*38
Green
D-Besk
35
0.95
Order Sample
LCRFDC2238
610*610*38
Green
D-Besk
35
0.95
Order Sample
LCDSC6625
600*600*25
Green
S-Besk
30
0.95
Order Sample
LCDSC2225
610*610*25
Green
S-Besk
30
0.95
Order Sample
